9.99 USD

FORMAT: PDF
SIZE: 19MB

ENGINE SPECIFICATION
Engine type.......................Liquid cooled 4-stroke, DOHC
Displacement......................998.0 cm
Cylinder arrangement..............Forward-inclined parallel 4-cylinder
Bore stroke.....................78.0 52.2 mm (3.07 2.06 in)
Compression ratio.................12.70 : 1
Standard compression
pressure (at sea level)...........1480 kPa/350 r/min (14.8 kgf/cm/350 r/min,
210.5 psi/350 r/min)
MinimumMaximum...................12901660 kPa/350 r/min (12.916.6 kgf/cm/
350 r/min, 183.5236.1 psi/350 r/min)
Starting system...................Electric starter

CONTENTS:
GENERAL INFORMATION
SERVICE SPECIFICATION
PERIODIC CHECKS AND ADJUSTMENTS
TROUBLESHOOTING
ENGINE
CAMSHAFT
CYLINDER HEAD
CLUTCH
CRANKCASE
CRANKSHAFT
TRANSMISSION
COOLING SYSTEM
FUEL SYSTEM
BRAKE
SWINGRAM
CHAINDRIVE
CHASSIS
ELECTRICAL SYSTEM

---

Keywords: workshop service repair manual
File Size: 18.3 MBytes
