11.70 USD

FORMAT: PDF
SIZE: 16MB

APPLICABLE MODEL:
YZF-R6R
YZF-R6SR
YZF-R6RC
YZF-R6SRC

ENGINE SPECIFICATION
Engine type...............................................Liquid-cooled, 4-stroke, DOHC
Displacement............................................600 cm3 (36.61 https://www.tradebit.com)
Cylinder arrangement...............................Forward-inclined parallel 4-cylinder
Bore X stroke..65.5 44.5 mm (2.58 1.75 in)
Compression ratio..12.4 : 1
Engine idling speed...1,250 1,350 r/min
Vacuum pressure at engine idling
speed.........................................................24 kPa (180 mmHg, 7.0872inHg)
Standard compression pressure
(at sea level)...1,550 kPa (15.50 kg/cm2,15.50 bar, 220.46 psi) at 400 r/min

CONTENTS:
GENERAL INFORMATION
SERVICE SPECIFICATION
PERIODIC CHECKS AND ADJUSTMENT
CHASSIS
ELECTRICAL SYSTEM
WHEEL AND BRAKE DISCS
STEERING
SWINGRAM
DRIVECHAIN
ENGINE
CAMSHAFT
CYLINDER HEAD
CRANKSHAFT
CLUTCH
STARTER
CRANKCASE
CRANKSHAFT
COOLING SYSTEM
FUEL INJECTION SYSTEM
IGNITION SYSTEM
TROUBLESHOOTING
WIRING DIAGRAM

---

Keywords: workshop service repair manual
File Size: 15.2 MBytes
