14.50 USD

FORMAT: PDF
SIZE: 37MB

ENGINE SPECIFICATION:
Engine Type............4-stroke, single cylinder, DOHC 4 valve
Cooling System...................Liquid-cooled
Bore and Stroke..................77.0 × 53.6 mm (3.03 × 2.11 in.)
Displacement......................249 cmł (15.2 cu in.)
Compression Ratio..............13.8:1
Fuel System.........................FI (Fuel Injection), KEIHIN 43
Starting System....................Primary kick
Ignition System....................Digital DC-CDI
Timing Advance...................Electronically advanced
Ignition Timing.....................BTDC 4° at 2 000 r/min (rpm)


CONTENTS:
General Information
Periodic Maintenance
Fuel System (DFI)
Cooling System
Engine Top End
Clutch
Engine Lubrication System
Engine Removal/Installation
Crankshaft/Transmission
Wheels/Tires
Final Drive
Brakes
Suspension
Steering
Frame
Electrical System
Appendix

---

Keywords: workshop service repair manual
File Size: 36.6 MBytes
